Separating responsibility in performance traces ⚖️

Separating app, framework, and system responsibility (Part 3)

piechart with four sections and in background mobile app

In Part 2, I focused on attribution:
figuring out which process and thread did the work.

That unlocked an important question I couldn’t ignore anymore:

When my app is slow,
how much of that work is actually mine?

Part 3 is about responsibility.

---

The uncomfortable truth about performance 🧠

Every mobile engineer has felt this moment:

• the UI thread is blocked

• frames are janky

• startup is slow

…and the trace looks terrifying.

But traces don’t care about blame.

They happily mix together:

• your app code

• Android framework internals

• system and kernel activity

Without separating those, it’s easy to draw the wrong conclusions.

Part 3 is about making that separation explicit.

---

From “who did the work” to “what kind of work it was” 🧭

At the end of Part 2, the analyzer could already say:

• which slices came from my app process

• which thread they ran on

• which app-defined sections dominated

But everything still lived in one bucket.

So in Part 3, I added a deterministic classification layer on top of that attribution.

Each slice is now labeled as one of:

• 🟢 app — work originating from app-defined sections

• 🔵 framework — Android UI / rendering / framework internals

• 🔴 system — scheduler, binder, SurfaceFlinger, kernel-level work

• ⚪ unknown — when we can’t be confident

No AI.
No guessing.
Just rules.

---

Classification is conservative (on purpose) 🧪

This part matters.

The classifier is intentionally boring:

• based on pid

• based on thread ownership

• based on small, explicit name-token rules

If a slice doesn’t clearly belong to a category, it becomes "unknown".

That’s not a failure — it’s honesty.

---

Long tasks, now with responsibility labels 🧵

Here’s what a long slice looks like now:

{
  "name": "UI#stall_button_click",
  "dur_ms": 200.1,
  "pid": 12345,
  "tid": 12345,
  "thread_name": "<main-thread>",
  "process_name": "com.example.tracetoy",
  "category": "app"
}

And a framework-heavy one:

{
  "name": "dequeueBuffer - VRI[MainActivity]",
  "dur_ms": 180.4,
  "pid": 12345,
  "tid": 111,
  "thread_name": "RenderThread",
  "category": "framework"
}

Same trace.
Very different implications.

---

Aggregates that change how you read traces 📊

Instead of eyeballing hundreds of slices, the analyzer now computes:

"work_breakdown": {
  "by_category_ms": {
    "app": 420.3,
    "framework": 1320.5,
    "system": 310.2,
    "unknown": 55.1
  }
}

This single block answers a powerful question:

Is this performance problem primarily app-owned?

Sometimes the answer is uncomfortable.
Sometimes it’s relieving.

Either way, it’s grounded.

---

Main thread blocking: who’s really at fault? 🚦

Part 3 also breaks down main-thread blocking time by category:

"main_thread_blocking": {
  "app_ms": 180.2,
  "framework_ms": 640.1,
  "system_ms": 95.0,
  "unknown_ms": 22.3
}

This is where responsibility becomes unavoidable.

If the main thread is blocked mostly by framework work,
optimizing app code won’t magically fix it.

---

A small but powerful summary 🧭

All of this rolls up into a minimal summary:

"summary": {
  "dominant_work_category": "framework",
  "main_thread_blocked_by": "framework"
}

This is not an explanation.

It’s a signal.

A signal that tells you where to look — and where not to.

---

What this is not doing 🚫

This system does not:

• assign blame

• generate advice

• claim causality

• pretend to understand intent

It simply makes responsibility visible.

That’s enough for now.

---

What’s next (Part 4) 🔮

In Part 4, I want to answer a different question:

When did this work actually matter?

That means:

• breaking the trace into time windows (startup vs steady state)

• correlating jank and stalls with those windows

• surfacing “what to look at first” signals

---

Links 🔗

• Repo:
  https://github.com/singhsume123/perfetto-agent

• TraceToy test app:
  https://github.com/singhsume123?tab=repositories

• Previous post (Part 2):
  https://substack.com/home/post/p-182558971

• Part 1:

  https://substack.com/home/post/p-182552580

---

Closing thought 💭

Performance traces don’t tell stories.
They tell facts.

Part 1 made them readable.
Part 2 made them attributable.
Part 3 makes responsibility explicit.

Only then can we talk about explanation.

---
